Rubber linings are barrier-type linings/coverings that are applied to equipment to protect from corrosion, abrasion, and chemical attack. For decades they have proven to be a reliable choice for protection of equipment in the Chemical Processing, Mining, Power Generation/Utility, Transportation, and Water Treatment industries.
Rubber lining materials are generally broken into two categories: natural rubber and synthetic compounds (generally a blend of natural and synthetic ingredients). Some common rubber lining types and uses are as follows:
- Soft natural – concentrated HCl, as well as sliding and impingement-type abrasion service
- Semi-hard/hard natural – strong acid solutions, plating solutions, wet chlorine and ion exchange water treatment vessels
- Chlorobutyl/bromobutyl – weather/ozone resistance, sodium hypochlorite solutions, acid/caustic solutions at elevated temperatures.
- Ethylene propylene diene monomer (EPDM) – oxidizing solutions, weather/ozone resistance and certain solutions at elevated temperatures.
- Buna-nitrile – aliphatic hydrocarbons, abrasion and heat resistance
- Neoprene – good physical properties, ultraviolet (UV) and ozone resistance, slight to moderate oil resistance.
Thin-Film Linings and Coatings
Thin-film linings and coatings, by definition, are films that are less than 20 mils (0.020″) in thickness. These are generally spray-applied systems and can be used as lining systems when properly applied and holiday-tested – these can also be applied as an external coating system for protection of equipment in fume, splash, and spill exposure.
Thin-film systems used as linings require a higher standard of surface preparation than those used as external coating systems. Equipment design and fabrication quality are key in achieving a continuous lining system free of voids or defects that can adversely affect long-term performance. These lining systems are generally designed for immersion in mildly-corrosive chemical solutions, or in situations where product purity or product release is a critical factor.
Typical thin-film lining systems include:
- Baked phenolics
Typical thin-film coating systems include:
- Inorganic and organic zinc primers
- High-heat silicones
Thick-film linings are generally recognized as liquid-applied lining systems in excess of 20 mils (0.020″) total dry film thickness.
These are selected as barrier-protection for harsh chemical environments and highly-corrosive service. As such, these linings undergo a high-voltage spark test to check the lining condition for continuity.
Thick-film linings can also be utilized to provide abrasion-resistance in slurry or dry-abrasive conditions.
Typical thick-film systems include:
- Vinyl esters
- Ceramic-filled or reinforced epoxy systems
- High-build, abrasion-resistant urethanes
Arbosol® Linings and Coatings
Arbosol is a liquid-applied, plasticized, heat-cured polyvinyl chloride (PVC) lining/coating system, known generically as plastisol. Arbonite is one of the most experienced and qualified applicators of plastisol coatings and linings, going back to our early beginnings in the 1950s.
Arbosol product advantages include:
- 100% solids – NO volatile organic compounds (VOCs)
- Proper surface preparation and the use of a chemical-bonding primer provide outstanding adhesion to the metallic substrate.
- Can be applied as a dip-coating or as a spray-applied coating system that allows for proper, continuous application on complex shapes and configurations with no seams.
- Range of durometer hardness options from 70 Shore A to 90 Shore A.
- Versatility – can be used as a tank lining system (minimum thickness of 60 mils) or as an effective barrier coating for the exterior of tanks, piping, and skids.
- Lining applications include sodium hypochlorite storage vessels, transport equipment, filter vessels in ion-exchange systems, plating equipment, and a large variety of pumps and valves.
- Food and Drug Administration – (FDA) – approved and National Sanitation Foundation (NSF)-61 certified versions available.
- Variety of colors available in spray versions; standard dip formulations are black.
Please contact us directly to learn more about how Arbonite can provide an Arbosol coating or lining solution for your difficult corrosion problems.
Not all lining installations are performed on new equipment and sometimes equipment cannot be removed from the service area for lining replacement. In addition, all installed lining systems require preventative maintenance inspections and periodic repair. In these circumstances, we can bring our unmatched expertise and service to your doorstep.
Arbonite offers a full range of mobile lining application, inspection, and repair services utilizing properly trained technicians capable of performing the highest quality of work in a safe and efficient manner.
- Arbonite is PA Department of Environmental Protection (DEP)-certified to perform “TL” activities on all storage tanks regulated pursuant to the Storage Tank and Spill Prevention Act (35 P.S. Section 6021.101) – Company Certification No. 1228.
- Our personnel are certified to NACE Certified Inspection Program (CIP) Level I.
- Our personnel are fully-trained to operate safely in accordance with all current Occupational Safety and Health Administration – (OSHA) – regulations.
- Our personnel are enrolled in the Transportation Worker Identification Credential (TWIC) program.
- On-site application and/or repair services offered include: rubber linings, thin-film linings (e.g., epoxies and baked phenolics), thick-film linings (e.g., vinyl esters and Novolac epoxies), Koroseal® polyvinyl chloride (PVC) sheet, and plastisol lining repairs.
- Mobile Department of Transportation (DOT) lining inspection and repair services for liquid bulk carriers – Company Certification No. CT-5752.
- Quick response is available for emergency on-site repairs.
Whether you have a large on-site lining application or a small, emergency lining repair, we provide the knowledge and service that you require to get your equipment back into service quickly at the lowest possible financial cost.
Please contact us directly to learn more about how Arbonite can provide an on-site coating or lining solution for your difficult corrosion problems.
Liquid Bulk Carriers – DOT Inspections
Arbonite is registered with the US Department of Transportation (DOT) to perform lining (L) and internal visual (I) inspections to lined, liquid bulk carriers in accordance with Section 107.503 of Title 49, Code of Federal Regulations (49CFR). Our registration ID number is CT-5752.
We are capable of performing inspections and subsequent repairs to most types of trailer linings. Additionally, we can also perform the following complete lining installations in liquid bulk carriers:
- Soft natural and pure gum rubber
- Chlorobutyl rubber
- Ethylene propylene diene monomer (EPDM) rubber
- Baked phenolics
- Vinyl esters
- Epoxies, epoxy-phenolics and epoxy-novolacs
- Arbosol polyvinyl chloride (PVC)
If your trailer is mild-steel and painted on the exterior, we are capable of removing the existing paint and applying a new external paint system.
We understand that it is not always convenient to send a trailer to our facility. For this reason, we offer mobile liquid bulk carrier inspection and repair services as well.
Arbonite is a skilled applicator of Koroseal sheet polyvinyl chloride (PVC) lining systems.
- Koroseal is an extruded, plasticized, PVC sheet membrane combining the chemical resistance of polyvinyl chloride with the flexibility for relative ease of application.
- The lining system is engineered to resist oxidizing and non-oxidizing acids, as well as mild alkalis and salts at operating temperatures up to 150°F.
- Koroseal tank lining applications require the use of skilled and experienced technicians to provide long-lasting protection of tanks used in chrome, nickel, copper, and zinc plating solutions.
- Whether at our shop or at your facility, we are capable of performing complete lining applications on new or used equipment, or repairs of existing Koroseal lining systems.
Please contact us directly to learn more about how Arbonite can help you with the application and/or maintenance of your Koroseal tank lining system.
Darkar NoSkid™ Coating
Darkar NoSkid is a patented, vinyl-based, anti-slip coating system with an integral grit fused into the coating. Arbonite is the exclusive applicator of Darkar NoSkid materials.
This coating system is traditionally used in transport equipment, specifically in passenger railcars. As such, it meets or exceeds federal requirements as outlined in Federal Railroad Administration 49 CFR 238.103.
Product features include:
- Specified thickness ranges from 40 mils to 125 mils.
- Coating system is chemically-bonded to stainless steel, aluminum, or mild steel to provide superior adhesion to the substrate.
- The applied coating system is resistant to a wide range of acids and alkalis and also displays excellent abrasion resistance.
- Can be applied to a wide variety of shapes and sizes and can also be utilized in conjunction with heating elements.
- Standard colors are gray, black, and yellow – additional colors available upon request, and multi-color applications for safety/visibility are also performed.
Darkar NoSkid coatings have undergone the following tests to be deemed suitable for use in passenger railcars:
- ASTM D-2047-93 Static Coefficient of Friction
- NFPA 259-98 Potential Heat of Combustion
- ASTM E-648/NFPA 253 Critical Radiant Flux of Floor Covering Systems
Please contact us directly to learn more about how Arbonite can provide a Darkar No-Skid coating solution for your passenger railcar components.
Established in 1953, the Arbonite Division of Valjon Industries, Inc. is one of North America’s leaders in the application of protective coatings and linings.
Our customers include organizations in these industries:
- Power generation
- Water and waste treatment
- Chemical processing and manufacturing
- Metal plating
- Pharmaceutical manufacturing
- Liquid bulk transportation
- Milling and mining
Either at our 45,000-square foot facility in Doylestown, PA or on-site at your facility, Arbonite is fully capable of meeting your company’s most challenging coating and lining needs.
To provide our valued clients with custom solutions to complex corrosion problems at the lowest possible cost per year of service, all while making it easy for the client to do business with us.
To provide a safe, fair, and diverse working environment for our employees which enables them to perfect their trade and empowers them to interject with ideas for continuous process improvement.
To expand on our existing capabilities by continuously updating our knowledge and experience with regard to the constantly-evolving technologies of our industry, always with respect to our neighbors and the environment.
